Adastra LP8V 8 inch, 60W, 100V Line & 8 Ohm Low Profile Ceiling Speaker

DETAILS

The Adastra LP8V is a 2-way ceiling speaker with flared baffle and a low profile magnetic grille, perfect for stores, offices & restaurants.

LP8V is 8 inches in size with a power rating of 60W rms.

The main driver with concentric directional tweeter is operated via a rotary control with 5 x 100V volume tappings and an 8 Ohms option.

Mount into suspended or false ceilings using the 4 “dog-ear” mounts to achieve a discreet, high-quality sound installation.

Adastra LP8V Key Features:

• Rotary selector switch for 100V line tappings or 8 Ohms

• Magnetic frameless grille

• Fitted with “dog-ear” mounts for fixing to suspended or false ceilings

• Discreet, low profile installation

• Grille can be painted to match decor

• Supplied singly

SPECS & DOWNLOADS

Adastra LP8V Specifications

• Model: LP8V
• Woofer: 200mmØ (8″)
• Tweeter: 44mmØ (1.75″)
• Frequency response: 60Hz – 20kHz
• Power max.: 8 Ohms120W
• Power rms: 8 Ohms60W
• Power rms: 100V line50W
• Cutout: 245mm
• Mounting depth: 104mm
• SPL @ 1W/1m: 89dB (±2dB)
• Tappings: 10, 20, 30, 40, 50W & 8 Ohms
• Dimensions: 108 x 281mmØ
• Weight: 1.98kg
