W-Audio DTM 10-Way Wireless UHF Headset & Lapel Microphone System V2 (CH38/70)
DETAILS
W Audio DTM 10-Way Wireless UHF Headset & Lapel Microphone System – Channel 38/70 Hybrid Setup for Schools, Theatres and Venues.
The W Audio DTM 10-Way Wireless Microphone System offers a practical and flexible UHF solution for use in schools, theatres, houses of worship, and public venues.
This system includes ten microphone channels via five dual-channel receivers and is configured as a hybrid bundle, comprising 8 channels on UHF Channel 38 (606.0–614.0MHz) and 2 channels on Channel 70 (863.0–865.0MHz). This combination allows for greater installation flexibility and compliance across different environments.
Each receiver in the system supports two beltpack transmitters simultaneously, enabling the concurrent use of up to ten microphones. The system includes both headset and lapel microphones for each transmitter, giving users the choice of hands-free performance or discreet vocal reinforcement. Headsets are ideal for performers or presenters who require freedom of movement, while lapel microphones provide subtle and effective vocal pickup for talks, lectures or ceremonies.
With 300 selectable frequencies, auto-scanning, and spectrum analysis, the DTM 600 system ensures reliable operation and minimal risk of interference. The transmitters and receivers both feature backlit LCD screens displaying real-time information such as channel, frequency, RF and AF levels. IR sync functionality allows for fast pairing between devices, while balanced and unbalanced outputs offer flexibility for integration into different audio systems.
The DTM 600 series is compatible with other microphones in the W Audio Diversity range—including handheld transmitters—providing a future-proof solution that can be tailored to meet the needs of different types of users and events.
W-Audio DTM 10-Way Mic System Key Features:
- 10-way microphone system with 8 x Channel 38 and 2 x Channel 70 operation
- 300 user-selectable UHF frequencies with auto-scan and spectrum display
- Five dual-channel DTM 600 receivers, each accepting two transmitters
- Ten wireless beltpack transmitters included
- Supplied with 10 x headset microphones and 10 x lapel microphones
- Compatible with other W Audio Diversity Series transmitters including handhelds
- Rack-mountable receiver design for fixed and touring applications
- LCD displays on receivers and transmitters showing RF level, AF level, channel and frequency
- IR sync for quick transmitter-receiver pairing
- Balanced XLR outputs for each channel and unbalanced mixed output
- Phase Locked Loop (PLL) circuitry for transmission stability
What’s Included:
- 4 x DTM 600 UHF Receivers (CH38)
- 1 x DTM 800 UHF Receiver (CH70)
- 10 x Wireless Beltpack Transmitters
- 10 x Headset Microphones
- 10 x Lapel/Tie-Clip Microphones
- 5 x Power Supplies
- 5 x ¼” Jack to Jack Connecting Cables
- User Manuals
SPECS & DOWNLOADS
Download the User Manual HERE >
W-Audio DTM 600 Specifications
- Frequency response: (handheld): 40Hz-15kHz
- Transmitter battery configuration: 2 x 1.5V AA (not supplied)
- Audio output level: 400mV
- Rack Mount: Included
- Dynamic range: 96dB
- Receiver power supply: 12V DC (mains adaptor supplied)
- Software Version: 2
W-Audio DTM 800 Specifications
-
Frequency response: (handheld): 40Hz-15kHz
- Transmitter battery configuration: 2 x 1.5V AA (not supplied)
- Audio output level: 400mV
- Rack Mount: Included
- Dynamic range: 96dB
- Receiver power supply: 12V DC (mains adaptor supplied)
- Software Version: 2
W-Audio DTM 600BP Specifications
- Includes: 1x Transmitter, 1x Headset Mic, 1x Lavalier Mic
- Beltpack dimensions: 100 x 65 x 30mm
- Battery type: 2 x 1.5V AA (not supplied)
