Trade Pack – 8x Bosch LHM 0606/10 6″ 100V In-Ceiling Speakers
DETAILS
Pack of 8x Bosch 100V Ceiling Speakers designed for audio installations into commercial and residential properties.
The Bosch LHM0606/10 is a professional install speaker designed for low-level background music applications and speech in a wide range of environments from restaurants and cafes to small retail stores and office spaces.
This 6-inch flush-mounted speaker is incredibly easy to install and is very discrete and unobtrusive, making it especially handy for buildings with low ceilings or a lot of wall-decorations.
Simple Setup
These in-ceiling speakers from Bosch are extremely quick and easy to install saving you lots of valuable install time.
The LHM0606/10 operates on 100V Line and has multiple power tapping allowing it to be balanced to the majority of 100V amplifiers.
The speaker has a black connection (earth) and 1x Yellow (1.5w) 1x Blue (3w) and 1x Red (6w). To achieve 6w simply connect the black and red cables (6w).
Exclusive Trade Pricing
Here at Audio Volt we work very closely with trade professionals and are pleased to provide them with discounted trade pricing.
There is no conflict of interest as we do not offer an installation service and we will never contact your customer direct unless requested by yourself.
Our main goal is to supply the equipment and provide both product and technical advice pre and post-sale. We also offer a FREE no-obligation system design service.
If you are an electrician, builder, shopfitter or a similar trade professional then you can make the most of our trade prices today!
See SPECIFICATION tab for technical specs
SPECS & DOWNLOADS
BOSCH LHM0606/10 Ceiling Speaker Specifications
- Transformer Power Tappings: 6W, 3W, 1.5W
- Frequency Response Min: 80Hz
- Frequency Response Max: 18kHz
- External Width: 199mm
- External Depth: 70.5mm
- Loudspeaker Diameter: 6 “
- Behind Panel Depth: 54.5 mm
- Sound Level SPL: 94 dB
- Panel Cutout Diameter: 165 mm
- Operating Temperature Min: -25 °C
- Input Voltage: 100 V
- Power Max: 9 W
- Colour: White
- Power Rating RMS: 6 W
- Weight: 620 g
- Operating Temperature Max: 55 °C
BOSCH LHM0606/10 Ceiling Speaker – PDF file downloads
Download the Data Sheet HERE
Download the Declaration of Conformity HERE
Download the Cut-Out Template HERE
