Q Install SUB80SP 8 inch, 100W In-Ceiling Subwoofer (Single)
DETAILS
The Q Install SUB80SP is an 8″ in-ceiling/in-wall subwoofer optimised for high-performance home cinema and music applications.
The 8” Subwoofer features Q Install’s superior Nano Particle mass damped polypropylene low frequency drive units with high powered coil and magnet assemblies for low distortion and high transient power capability.
The 8” Subwoofer features low profile magnetic grilles for ease of installation, with optimised whole geometries for their frequency range.
High order crossovers are used to ensure a smooth frequency transition on two and 3 way units, particular care has been taken to ensure that speech remains clear at all times via attention to the mid-range frequency response and reduction of all sources of colouration.
Installation is made particularly flexible by ensuring that all units require the minimum of installation depth, the maximum rear depth required is just 99mm for the Qi Sub 80SP.
If you require any further assistance regarding our Q Install range just contact us on 02476 369890 and one of our experts will be happy to help. Or use our Request a Call Back page for a FREE no obligation system design & consultation service.
View the Q Install range of products HERE
See SPECIFICATION tab for technical specs
SPECS & DOWNLOADS
Q Install SUB80SP In-Ceiling Subwoofer
- Tweeter / Tweeter diameter: n/a
- Woofer diameter: 8.0″
- Power handling (program): 15 – 100W
- Impedance (nominal) ohms: 8
- Sensitivity dB spl (2.83V, 1m): 88 (switchable HF)
- Response (Low frequency) -3 dB: 50 Hz
- Max rear depth: 99 mm
- Size: Round / Square grilles: 287 mm x 287 mm
- Cutout (nominal): 248 mm
