Muxlab Stereo RCA/Phono HiFi Balun PAIR – Audio over CAT5E/6 Adapter
DETAILS
With a frequency range of 20Hz – 20’000Hz, the Balun can be used for any application with no frequency or sound quality loss.
The Balun is passive and requires no mains power. This does mean it’s only suitable for use with powered equipment, it’s not compatible with passive speakers or microphones for example.
Muxlab Stereo RCA/Phono HiFi Balun PAIR
-
Extend stereo Hi-Fi audio signal distances up to 3,250ft / 1km via single Cat5e/6
-
Comes as a PAIR
-
Frequency response: 20Hz to 20kHz (over distance range)
-
Color coded RCA cable leads (male plugs)
-
Lifetime Warranty
SPECS & DOWNLOADS
Environment: Line level unbalanced analogue audio
3dB Bandwidth: 20 Hz to 20 KHz over the distance range
Maximum Input: 1.1Vp-p (unbalanced)
Insertion Loss per balun pair: Less than 2 dB over the frequency range.
THD: Maximum 0.007% @ 1 KHz over distance range.
Audio Source Impedance: 100 ohms maximum
Audio Receiver Impedance: 10 k ohms minimum
Max. Distance – Cat5e/6 UTP: 3,250 ft (1km)
Pin Configuration (RJ45) EIA 568 A or B:
- Audio 1 (White): pins 1[R] & 2 [T]
- Audio 2 (Red): pins 3 [R] & 6 [T]
Cable – UTP: 24AWG or lower solid copper twisted pair wire
- Impedance: 100 ohms at 1 MHz; Maximum capacitance: 20 pf/foot.
- Attenuation: 6.6 dB/1000 ft at 1 MHz
Cable: Coax Shielded audio cable
Connectors:
- 500028: Two (2) RCA-M 6” cable leads
- 500028-F: Two (2) RCA-F
- One (1) RJ45
Temperature Operating: 0º to 55º C. Storage:-20º to 85º C. Humidity: up to 95%
Enclosure: ABS. Fire retardant plastic
Dimensions: 2.40” x 2.25” x 1.00” plus 6” audio lead (500028)
Weight: 3.1 oz (89 gms)
Warranty: Lifetime
