Fonestar SONORA-8TB/8TN 8″ IP66 Wall Speaker (Single) 100V/8Ω – White or Black
DETAILS
The Fonestar SONORA-8TB/8TN is a high-performance sound reinforcement loudspeaker featuring a built-in 100 V line transformer.
Suitable for demanding public address and ambient sound applications and engineered for both outdoor and marine environments, this speaker is constructed with a powder-coated aluminium grille and has an IP-66 waterproof rating, ensuring durability against harsh weather conditions.
With a wide frequency response of 60-20,000 Hz, the SONORA-8TB/8TN delivers clear, distortion-free audio, making it perfect for commercial environments that require reliable sound distribution. It features multiple 100V power tappings (80W, 40W, 20W, 10W) and can also operate at a low impedance of 8 Ohms, providing flexibility for various installation requirements.
Fonestar SONORA-8TB/8TN Key Features:
- Low impedance loudspeaker with built-in 100 V line transformer.
- Designed for outdoor use, featuring waterproof and rustproof materials.
- Power: 150 W max, 100 W RMS.
- Speaker Components: 8″ polypropylene woofer and 1″ tweeter.
- Sensitivity: 89 dB @ 1 W/1 m.
- Maximum Sound Pressure: 108 dB @ max. W/1 m.
- Coverage Angle: H/V: 210º/210º @ 500Hz, 120º/120º @ 1kHz.
- Protection Rating: IP-66, complying with EN 60529 standards.
- Easy cable connections via Euroblock in and out for 0.25 – 2.5 mm² cross-section cables.
Fonestar SONORA-8TB/8TN is Ideal For:
- Public address and background music in commercial spaces such as cafés, restaurants, and bars
- Outdoor sound systems in gardens, patios, and terraces
- Ambient audio in retail environments like supermarkets and shopping centres
- Coastal installations where resistance to salt and moisture is essential
- Versatile applications requiring high-quality sound in varied environments
SPECS & DOWNLOADS
Fonestar SONORA-8TB/8TN PDF Spec Sheet > DOWNLOAD HERE
Fonestar SONORA-8TB/8TN Specifications
-
Power: 150 W max., 100 W RMS
-
Loudspeakers: 8″ polypropylene woofer, 1 x 1″ tweeter
-
Frequency Response: 60-20,000 Hz
- Impedance: 100V, 8 Ω
- 100V Power Tappings: 80W, 40W, 20W, 10W
-
Sensitivity: 89 dB @ 1 W/1 m
-
Maximum Sound Pressure: 108 dB @ max. W/1 m
-
Coverage: H/V: 210º/210º @500Hz, 120º/120º@1kHz, 110º/110º@2kHz, 110º/110º@4kHz (-6 dB)
- Material: ABS (UV resistance), Aluminium mesh grille, with powder-coated finish, Weather-resistant mount, Stainless steel screws
-
Switch: W selector in high Z and low Z
-
Connectors: Euroblock in and out for cable 0.25 – 2.5 mm² cross section
-
Temperature Range: -10°C ~ 60°C
-
Colour: White (RAL 9003), Black (RAL 9005)
- Dimensions: Loudspeaker: Speaker: 235 x 380 x 205 mm depth, Wall plate mount: 102 x 165 mm, Speaker with mount: 305 mm deep
- Weight: 5.3 kg
