Cloud CS-S10 10″ Passive Wall Mount Loudspeaker 8Ω 250W, Single – Black or White
DETAILS
Cloud CS-S10 10″ Passive Wall Mount Loudspeaker 8Ω – Robust Audio Performance for Large Venues.
The Cloud CS-S10 is a 10” two-way passive loudspeaker ideal for both indoor and outdoor installations in leisure, hospitality, and large-scale event venues. It is designed to deliver high-quality sound with more volume and improved musical reproduction compared to typical background music speakers, making it perfect for front-of-house applications.
Built from LLDPE (Linear Low-Density Polyethylene), the CS-S10 offers a lightweight yet durable construction, ensuring it withstands the elements for outdoor use while maintaining its robust performance indoors.
Exceptional Sound Quality for Larger Spaces
The CS-S10 is capable of handling 250W continuous power and delivering 375W peak power, making it suitable for venues that require high SPL levels. With a 93dB sensitivity (1W/1m) and a 118.5dB Max SPL, the speaker can fill larger spaces with clear, dynamic audio, perfect for high-traffic environments such as bars, gymnasiums, and large retail or entertainment areas.
Flexible Installation Options for Easy Setup
Featuring an integrated 1.375” pole mount cup and a sliding guide mechanism, the CS-S10 can be easily mounted to a variety of surfaces, such as poles, beams, or floodlights. The sliding guide mechanism enables the installer to position the speaker with both hands free, ensuring a secure and efficient installation process. With M6 mounting points for third-party brackets, the speaker is versatile for different installation scenarios. The safety cable fixing point ensures secure mounting, making installation quick and safe.
Cloud CS-S10 Key Features:
-
10” treated paper woofer with a cloth-treated surround for enhanced bass response
-
1” exit compression driver for clear high-frequency reproduction
-
Dual concentric driver design for consistent off-axis performance
-
8Ω impedance
-
250W continuous power / 375W peak power
-
93dB sensitivity (1W/1m), 118.5dB Max SPL
-
Integrated 1.375” pole mount cup with sliding guide mechanism for convenient mounting and positioning
-
M6 mounting points for third-party bracket compatibility
-
Safety cable fixing point for secure installation
-
Optional accessories (sold separately):
-
U-Bracket (CS-BRK810) – Black or White, powder-coated steel
-
IP66-rated weatherproof plate (CS-IP66) – Black or White, powder-coated aluminium
-
SPECS & DOWNLOADS
Download the Product Data Sheet HERE >
Cloud Electronics CS-S10 Specifications
Driver
- Type: 2-way coaxial
- Response (f3): 65 Hz – 20 kHz
- Response (f10): 55 Hz – 20 kHz
- Impedance: 8 ohms
- Crossover frequency: 1.6 kHz
- Sensitivity (1 W input @ 1 m): 93 dB
-
Power rating:
- Continuous: 250 W
- Peak: 375 W
- Maximum SPL: 118.5 dB (117 dB for A & AD versions)
- Average coverage angle (2-10 kHz): 95°
- Tweeter: 1” compression driver
- Woofer: 10” treated paper, treated cloth surround
Physical
- Enclosure type: Surface-mounting, vertical or horizontal
- Enclosure construction: Linear low-density polyethylene
-
Dimensions & Weight:
- Net dimensions: 429 mm x 318 mm x 280 mm (16.89” x 12.52” x 11.02”)
- Shipping dimensions: 480 mm x 380 mm x 360 mm (18.90” x 14.96” x 14.17”)
- Net weight: 10.35 kg (23.18 lb)
- Shipping weight: 11.57 kg (25.92 lb)
