Bose DesignMax DM3P 3.25″ High-Power Pendant Loudspeakers, Pair – Black or White
DETAILS
The Bose DesignMax DM3P 3.25″ High-Power Pendant Loudspeakers are engineered to provide clear highs and a surprising low-end performance for commercial indoor environments, such as retail stores, restaurants, conference centres, and hospitality venues.
Featuring a coaxial two-way design, each 30-watt speaker is equipped with a 3.25-inch woofer and a 0.75-inch tweeter, delivering a wide frequency range of 75 Hz to 20 kHz. The DM3P utilizes Bose’s Dispersion Alignment system to ensure consistent sound coverage throughout the room, providing an optimal listening experience without the need for additional DSP or EQ.
Constructed with durable materials for indoor use, the DM3P showcases a sleek design with a recessed single-point suspension system for a modern and attractive appearance. Available in black or white with a minimum-bezel grille and a removable logo, these pendant loudspeakers blend seamlessly into any setting while providing high-quality audio performance.
Bose DesignMax DM3P Key Features:
-
Clear Audio Performance: With a coaxial 3.25-inch woofer and a 0.75-inch tweeter, the DM3P delivers a frequency range of 75 Hz to 20 kHz, offering clear highs and impressive low-end for its size. The Dispersion Alignment system aligns the acoustic pattern of the woofer with that of the tweeter for consistent sound coverage.
-
Sleek, Modern Design: The DM3P features a recessed single-point suspension system, giving it a sleek and attractive appearance. Available in black or white with a rotatable and removable logo, the loudspeaker easily blends with any room design.
-
Flexible Installation: The DM3P comes with a Euroblock connector and a single suspension attachment point, allowing for straightforward installation. Its 130° conical coverage pattern ensures even sound distribution across the area.
-
Versatile Applications: Ideal for a wide range of commercial settings, including retail stores, restaurants, conference centers, hospitality spaces, and more. The DM3P can be combined with other DesignMax models to create a tailored sound solution.
Enhance Your Commercial Audio Experience
The Bose DesignMax DM3P Pendant Loudspeakers offer exceptional sound quality and versatile design, making them an excellent choice for enhancing the audio atmosphere in any indoor commercial space. With their sleek design and superior sound performance, they provide a reliable audio solution for various environments.
Choose Bose for Professional Audio Solutions
With the Bose DesignMax DM3P, you get a blend of high-quality sound and sleek aesthetics. Whether you’re setting up an audio system for a restaurant or a retail environment, these pendant loudspeakers deliver the performance and reliability Bose is known for.
In the Box:
- 2 x DesignMax DM3P Pendant Loudspeakers (Black or White)
- 2 x Suspension Cables (4.5m)
- 8 x Cable Ties
- 1 x Installation Guide
- 2 x Cable Fastener Tools
- 2 x Cable Fasteners
SPECS & DOWNLOADS
Bose DesignMax DM3P PDF Spec Sheet > DOWNLOAD HERE
Bose DesignMax DM3P Specifications
Physical:
- Colours: Black (similar to RAL 9005), white (similar to RAL 9003)
- Enclosure Material: Engineered plastics
- Environmental Testing: Indoor only
- Grille Material: Perforated steel, powder-coated finish
- Logo: Rotatable, removable
- Mounting/Rigging Provisions: 1 suspension attachment point, 1 safety cable attachment point
- Net Weight: 5.5 lb (2.5 kg), single
- Operating Temperature: 0 °C to 50 °C (32 °F to 122 °F)
- Product Dimensions (H×W×D): 8.2 in × 9.8 in (207 mm × 248 mm), loudspeaker diameter × depth / 15.0 ft × 0.1 in (4.6 m × 2 mm), suspension cable length × diameter
- Shipping Weight: 15.4 lb (7.0 kg), pair
Performance:
- Frequency Range (-10 dB): 75 – 20,000 Hz
- Coverage, Horizontal: 130° conical
- Maximum SPL at 1 m: 99 dB
- Nominal Impedance: 8 Ω (transformer bypass)
- Power Handling, Continuous: 25 W
- Power Handling, Peak: 100 W
- Sensitivity (SPL/1 W at 1 m): 84 dB
- Transformer Taps, 100V: 6, 12, 25 W, bypass
- Transformer Taps, 70V: 3 W, 6 W, 12 W, 25 W, bypass
- Coverage, Vertical: 130°
Transducers:
- Crossover Frequency: 1.7 kHz, passive 2-way crossover
- Driver Protection: Recommended high-pass protection 80 Hz with minimum 24 dB/octave filter
- High-Frequency Transducer Quantity and Size: 1 × 0.75 in (20 mm) neodymium dome tweeter, coaxially mounted
- Low-Frequency Transducer Quantity and Size: 1 × 3.25 in (83 mm) woofer
