AUDAC WX802 MK2, 2-Way 8 inch Wall Speakers, 100V/16 Ohm, Pair (Black or White)
DETAILS
The AUDAC WX802 is a high-performance 2-way wall-mounted speaker designed to deliver clear and powerful sound reproduction for a wide range of applications.
Offering true-to-nature, high-fidelity audio, it is perfect for both music playback and speech reinforcement in environments such as conference rooms, retail spaces, restaurants, and more. The WX802 ensures exceptional audio clarity and balance, making it an ideal choice for various commercial and residential settings.
Equipped with an 8” low-frequency driver and a 1” dome tweeter, the WX802 provides a robust sound profile with rich bass, smooth mids, and crisp highs. Capable of handling 70W power in a 16Ω setup, it also supports 70V/100V line systems with multiple power taps (60W, 30W, and 15W), allowing for flexible installation in large-scale distributed audio systems. The sleek and durable synthetic enclosure is available in black or white, ensuring seamless integration into modern, traditional, or design-centric interiors.
Flexible Installation & Reliable Performance
The WX802 features an adjustable steel mounting bracket for both vertical and horizontal mounting, with the ability to angle the speaker for optimal sound coverage. The new terminal block connection (MK2 series) ensures faster and more reliable installation, while daisy-chaining is simplified with additional 4-pin connection terminals. An advanced protection network prevents overloads, safeguarding the tweeter and extending the speaker’s longevity.
AUDAC WX802 Key Features:
- 2-Way Speaker – 8” low-frequency driver + 1” dome tweeter for high-fidelity sound
- Flexible 16Ω & 70V/100V Operation – Supports multiple power taps (60W, 30W, 15W)
- Clear, Balanced Audio – Ideal for both music and voice applications
- Durable Synthetic Enclosure – Available in black or white for seamless integration
- Vertical & Horizontal Mounting – Adjustable steel bracket for optimal positioning
- Terminal Block Connection (MK2) – Faster and more reliable installation
- Daisy-Chaining Made Easy – Additional 4-pin connection terminals for streamlined wiring
- Advanced Protection Network – Protects the tweeter from overload and damage
- Rotatable AUDAC Logo – Ensures a professional appearance in any orientation
- 5-Year Warranty – Built for long-term reliability and backed by AUDAC’s 5-year manufacturer warranty
SPECS & DOWNLOADS
Download the PDF Data Sheet HERE >
AUDAC WX802 Specifications
- Crossover: Frequency 2.4 kHz / Type Passive built-in
- Drivers: HF 1” / LF 8”
- Frequency Range (-10 dB): 60 Hz – 18 kHz / Response (± 3 dB) 50 Hz – 20kHz
- Impedance: 16 Ω, 100V
- 100V Transformer Tappings: 60W, 30W, 15W
- Ingress Protection rating: IP40
- Sensitivity (1W/1m): 89 dB
- Sound Pressure (Max. W/1m): @ 100 V 106 dB / @ 16 Ω 106 dB
- Speaker type: 2-way
- Continuous power (AES): 70 W
- Peak power handling: 280 W
- Program power handling: 140 W
- Dispersion: Horizontal 110° / Vertical 110°
- Dimensions: 358 x 276.1 x 285.6 mm (W x H x D) (Incl. bracket)
- Weight: 7.5kg
- Operating temperature: -25 °C ~ 70 °C
- Construction: ABS
- Mounting & handling: Mounting bracket
- Front finish: Steel grill
