4-Zone Mosque/Masjid PA Speaker System with Radio Microphones & In-Ceiling Speakers
DETAILS
Complete PA speaker system for prayer halls & places of worship. Comes with a 4-zone amplifier, quad radio mic system & in-ceiling speakers.
Our Masjid PA Sound System is perfect for medium-sized places of worship that require a multi-room audio system for background music and speech.
This kit comes complete with a 4-zone mixer-amplifier that provides users with volume control & audio source selection for each zone. In addition to this, we have included wall-mount volume controls that so that the volume can be altered locally within each area.
A different audio source can be routed to each of the zones, for example a prayer may be sounding in the main worship hall with some soothing background music playing in the canteen area.
Also included in our multi-zone PA package is a quad radio microphone system that comes with a choice of wireless handheld, tie-clip/lapel & headset microphones. Up to 4 microphones can be used and mixed together at once.
In terms of audio inputs, our Masjid PA system has 5 input channels that enable users to connect external media devices such as a CD player, laptop/PC, TV or an external mixing desk that may have multiple instruments/microphones connected.
We are proud to offer our 4-zone Masjid PA system with a 3-year warranty.
What’s included in our Masjid PA System?
- 1x Clever Acoustics 480W 4-Zone Mixer Amplifier
- Up to 16 x Clever Acoustics 6″ In-Ceiling Speakers
- 4x 120W Wall Mount Volume Controls
- AudioKraft Apollo Premium Speaker Cable
- 1x Chord Quad Radio Mic System (NU4-C)
SPECS & DOWNLOADS
Clever Acoustics Amplifier Specifications
- Power output: 120Wrms / 135Wpeak
- Speaker output: 70V, 100V and 4-16 Ohms
- Frequency response: 50Hz-18kHz
- Power supply: 240V AC 50Hz / 24V DC
- Power consumption: 200W
- Dimensions (H x W x D): 88 x 484 x 303mm
- Weight: 7.8kg
Clever Acoustics Ceiling Speakers Specifications
- Version: CS 630HP
- Input: 100V, 8Ω
- Power taps @ 100V: 1.9W, 3.8W, 7.5W, 15W, 30W
- Impedance: 2.6KΩ, 1.3KΩ, 670Ω, 330Ω, 165Ω
- Power (RMS): 30W @ 8Ω
- Sensitivity (1W/1m): 89dB (±3dB)
- Maximum SPL (Rated W/1m): 104dB
- Frequency response: 95Hz-20kHz
- Drivers: 6″ LF, 1.5″ HF
- Connections: 2 x spring terminals
- Cutout: 208mmØ
- Mounting depth: 140mm
- Dimensions: 165 x 233mmØ
- Weight: 1.6kg
Double Insulated Speaker Cable Specifications
- CSA: 2 x 0.75mm²
- Strands: 2 x (12 x 0.2mmØ Cu + 12 x 0.2mmØ CCA)
- Dimensions: 7mmØ
- Current: 6A max.
- Sheath: Black PVC
- Length: 100m
